Testmo works with any test automation tool, including Ranorex, a suite of tools designed to provide end-to-end test automation for desktop, web, and mobile applications. This quickstart guide provides an overview of how to report Ranorex test automation results to Testmo.

Run Ranorex & generate XML file

Ranorex comes with full support for generating JUnit-style XML files, which has become a standard format to exchange test results between tools.

> <test-suite-name>.exe /ju

This will run your tests with Ranorex and automatically write all test results to an XML file in the results directory. You can also configure a different directory or use any other regular Ranorex command line options. You can learn more about generating JUnit-style files (also called XUnit files) in the Ranorex documentation for the command line and the user interface.

Submit test results to Testmo

To submit your test results to Testmo, you simply use our cross-platform testmo CLI tool. The CLI tool is distributed as an NPM package and is easy to install on any system. Simply install our official @testmo/testmo-cli NPM package:

> npm install -g @testmo/testmo-cli
> testmo -h

Usage: testmo [options] [command]
[...]

We can now send the Ranorex test results to Testmo. To do this, make sure to generate an API key in Testmo from your profile page. The API key is used to authenticate with Testmo to send the results. We can then use the testmo CLI tool to submit our results (note that we first set the TESTMO_TOKEN variable, which the tool expects):

Full example

Single line

> set TESTMO_TOKEN=********
> testmo automation:run:submit ^
  --instance https://<your-name>.testmo.net ^
  --project-id 1 ^
  --name "Ranorex test run" ^
  --source "unittests" ^
  --results results\results.xml

If you run this example on a single command line, make sure to remove the backspaces:

> set TESTMO_TOKEN=********
> testmo automation:run:submit --instance https://<your-name>.testmo.net --project-id 1 --name "Ranorex test run" --source "unittests" --results results\results.xml

See command output

Collecting log files ..
Found 1 result file with a total of 855 tests
Created new automation run (ID: 254)
Created new thread (ID: 608)
Sending tests to Testmo ..
Uploading: [|||||||||||||||||||||||||] 100% | ETA: 0s | 855/855 tests
Successfully sent tests and completed run
Marked the run as completed

That's it! 🎉 This will automatically analyze the XML result file, create a new test run in Testmo, submit all tests & results and mark the run as completed. There's no need to manually create any tests, map tests or IDs or build any custom API code. Everything is handled automatically for you.

➡️ Bonus: Launch Ranorex with Testmo CLI

In the above example, we first launched Ranorex to generate the XML file and then used our CLI tool to submit the results in a second step. As an improvement to the above example, we can ask our CLI tool to launch Ranorex (testmo then starts and waits for Ranorex to finish). This has the following additional benefits:

a) Capture full console output and send it to Testmo

b) Accurately measure test times

c) Record the Ranorex exit code

Launch Ranorex with CLI tool

We can ask our CLI tool to launch Ranorex, so we can capture the console output and more:

> set TESTMO_TOKEN=********
> testmo automation:run:submit ^
  --instance https://<your-name>.testmo.net ^
  --project-id 1 ^
  --name "Ranorex test run" ^
  --source "unittests" ^
  --results results\results.xml ^
  -- <test-suite-name>.exe /ju
    ^ space!

Also learn more and see other examples in the full Testmo CLI guide.

More resources & references

Now that you are familiar with submitting your Ranorex test results to Testmo, you might also find the following additional examples, topics, and references useful for more advanced workflows.
